This past April I moved to the Bernal Heights neighborhood in San Francisco. Quite a culture shock for me to be sure. Fairfax is a very differnt place.
This part of SF is about 15 minutes away from one of the major casual DH/Jump locations in the bay area, Pacifica. An odd thing about Pacifica, my downhill bike was too big to feel challenged. My trail bike is designed for prestine Marin singletrack, too small to charge the big hits at Pacifica. I needed a 6 inch bike but I didn’t feel like building one.
So I bought one…
Santa Cruz Butcher. No nonsense fun bike. 34.36 lbs. Rumble!
The Cane Creek Double Barrell shock. The sweetest thing. Gold!
PVD Bash/Slide 42. Ballistic!
Upgraded PVD shock reducers. Silly stock unit on the right.
Frame : Santa Cruz Butcher, Med, Blue |
Fork : Fox 160VAN FIT RC2 |
Fork Spring : 50 lb/in, Green, 039-05-103 |
Rear Shock : Cane Creek Double Barrel. 215 x 63mm (8.5″ x 2.5″). |
Shock Spring : 440 lbs x 63mm (145mm OAL) |
Shock Reducers : PVD Spherical Style (Stainless) |
Stem : Salsa SUL 100mm, 15 degree |
Handlebar : Truvaiv WC Flat 700mm |
Front Brake : Shimano Saint, BR-M810 |
Front Rotor : Shimano XTR, SM-RT98-L (203mm) |
Rear Brake : Shimano Saint, BR-M810 |
Rear Rotor : Shimano XTR, SM-RT98-S (160mm) |
Brake Hose : Shimano SM-BH59 |
Brake Hose End Cover : Shimano Y8H203000 |
Shifter Set : Shimano Deore XT10, SL-M770-10R |
Shift Cable : Shimano Dura-ace, 1.2mm, Y60098900 |
Shift Cable Ends : Cane Creek, Silver, 1.5mm |
Shift Housing : Shimano SP-41, 4mm |
Shift Housing End Caps : Shimano Sealed, Y6AM98080 |
Shift Housing End Cover : n/a |
BB Cable Guide : n/a |
Crank : Shimano Deore XT10, FC-M770-10 |
Crank Fixing Bolt : Shimano XTR #Y1E511000 |
Bottom Bracket : SM-FCM810 (or FSA) |
Bash Guard : PVD Bash/Slide 42T |
Pedals : Shimano XT Clipless, PD-M770 |
Front Derailleur : Shimano Deore XT10, FD-M770-10 |
Cassette : Shimano Deore XT10, CS-M771-10 (11-36) |
Rear Derailleur : Shimano Deore XT10, RD-M773, SGS |
Chain : Shimano XT10, CN-HG94 |
Front Hub : Shimano Saint, HB-M810 |
Front Rim : ZTR Flow Rim 32H Black |
Front Spokes : DT Swiss 1.8/1.6/1.8 |
Front Spoke Lacing : 3 Cross D, 3 Cross ND, Disc lace |
Front Nipples : DT Swiss 1.8mm x 12mm Alloy |
Front Skewer : n/a |
Rear Hub : DT Swiss 240s, 135×10 Thru |
Rear Rim : ZTR Flow Rim 32H Black |
Rear Spokes : DT Swiss 1.8/1.6/1.8 |
Rear Spoke Lacing : 3 Cross D, 3 Cross ND, Disc lace. |
Rear Nipples : DT Swiss 1.8mm x 12mm Alloy |
Rear Skewer : DT Swiss RWS 10mm TA/QR |
Rim Tape : 25mm Yellow Tape, Flow Rim Strip |
Inner Tubes : n/a |
Tire Sealant : No Tubes |
Front Tire : Kenda Nevi 2.35″ UST |
Rear Tire : Michelin Mountain X’Treme 2.2″ UST |
Upper Headset : Cane Creek ZS-3, 1.125″, 7mm |
Lower Headset : Cane Creek XXII, 1.5″, 11.7mm |
Grips : ODI Rouge Lock-on |
Seatpost : Thomson Setback 30.9, 400mm, 16mm |
Seatpost Shim : n/a |
Seatpost Clamp/QR : Santa Cruz OE |
Saddle : WTB Silverado Ti, 274mm |
Special thanks to Fairfax Cyclery and Cane Creek Cycling Components
